Non-destructive Testing

Anyone who wants to selectively control their production, must detect disturbances in the production at an early stage. Non-destructive testing by means of thermography provides important insights into the quality of compounds (e.g. layered compounds) or allows you to detect cavities even before the finished product is available.

Active Thermography as a Process for Non-destructive Testing

The essential feature of active thermography is the targeted supply of energy to the test object. A temporal and spatial characteristic heat flow results depending on the geometry and thermal properties of the test subjects. Its progression on the surface of the test object is captured by a thermographic camera.

The cooled high-end camera series ImageIR® and uncooled microbolometer cameras of the latest generation of the VarioCAM® series are particularly suited for depicting the resulting temperature distributions. The geometric resolution of up to (2,560 × 2,048) IR pixels, high refresh rates as well as exact triggering and thermal sensitivity well below 0.015 K provide the technical requirement for detecting the smallest material defects.

Rely on infrared thermography for non-destructive testing, benefit above all from the variable application of the process for different materials and material combinations. You can detect very different defects. This includes defects in joints, cavities, cracks or faulty joints. Thanks to such qualities, active thermography has firmly established itself as an efficient method for contactless and non-destructive testing in recent years.

Thermographic Automation Solutions by InfraTec

PV-LIT test solution for solar cells
Photovoltaic Test System - PV-LIT

Photovoltaic Test System - PV-LIT

Get advantages in costing and quality by non-contact thermographic testing of your solar cells and PV-modules.

Welding seams and welding spots testing with WELD-CHECK
Welding Inspection - WELD-CHECK

Welding Inspection - WELD-CHECK

Using pulse thermography, WELD-CHECK enables you a quantitative assessment of the inspected welds.

Thermographic automation for brake test benches TRC - Picture Credits: © iStock.com / ktsimage
High-speed Rotation Test Bench - TRC

High-Speed Rotation Test Bench - TRC

Check for long-life fatigue strength of mechanical components in load tests, using high-end infrared cameras.

Automated Testing Solution ACTIVE-LIT - Header - Picture Credits: © iStock.com / scorpp
Electronic / Semiconductor Testing Solution – E-LIT

Electronic / Semiconductor Testing Solution – E-LIT

Detect inhomogeneous temperature distribution and local power loss during the production using the Lock-in thermography.

Application Areas

  • Quality assurance for bonded, welded, soldered and other joints by means of cavity detections (e.g. on vehicle interior parts)
  • Detection of material defects in composites and cracks in metals
  • Quality assurance of intermediate products (e.g. layered compounds)
  • Localisation of defects in joints such as cavities, defective welding seams/points
  • Assessment of thermal cutting and injection processes
  • Testing of metallic and non-metallic materials/material compounds
  • Tests of internal structures, such as fractures or impacts in honeycomb lightweight constructions
Get in contact with InfraTec thermography division

Would You Like to Know More?

It is not unusual for tasks to be associated with special requirements. Discuss your specific application needs with our specialists, receive further technical information or learn more about our additional services.

Great Britain

InfraTec infrared Ltd
Dunston Innovation Centre, Dunston Road
 ChesterfieldUK

Non-destructive Testing: Benefits of Using Thermography

  • Effective prevention of test scrap
  • Contactless testing with low thermal stress
  • Meaningful depiction of the defects
  • Simple analysis of large, uneven surfaces
  • Categorisation of different types of defects
  • Extensive testing already on one-sided test
InfraTec service
Comprehensive Service from InfraTec

Comprehensive Service

Our Company’s own service department accompanies you even with complex automation solutions far beyond the actual sale. In the event of malfunctions, your enquiry is forwarded directly to the employees via a hotline. By remote maintenance, you will receive an initial diagnosis. Together with you, we analyse the cause of the problem and quickly find a solution.

InfraTec Service - Technical Support
Advice from Specialists

Advice from Specialists

For more than 25 years, InfraTec has been implementing thermographic solutions with partners worldwide. Based on this wealth of experience, a thorough analysis of the initial situation is one of the first steps in cooperation. We prepare feasibility analyses and advise you on the planning of your future thermographic system. Afterwards, you will receive an offer adapted to your specific requirements.

Thermography trainings
Training of your Employees

Training of your Employees

In our training centre in Dresden, you can attend practical thermography training courses. After the transfer of the turnkey system, upon request qualified employees of our service team will introduce you step by step to your automation solution and instruct future users on your premises.

Camera protective housing for infrared cameras by InfraTec
Wide Range of Protective Housings

Wide Range of Protective Housings

The InfraTec product range includes numerous protective housings. The all-weather and robust metal housings allow the use of the thermographic cameras in harsh environments and protect against mechanical stress, dust and splash water. Depending on requirements, users can also choose ATEX-certified protective housings that can be used in potentially explosive atmospheres.

InfraTec camera equipment
Ask for your suitable accessories

Suitable Accessories for Extended Requirements

InfraTec offers high-quality accessories for all camera series. This allows users to flexibly adapt their camera to changing test and measurement environments and optimize it for daily indoor and outdoor use. The corresponding components are specially designed for the corresponding model and open up new possibilities – for current applications and new tasks.
