Ther­mo­graphic Biologic and Geologic Studies

Detect minimal thermal reactions to environmental stimuli and changes

  • Excellent thermal resolution allows for detection of smallest signals

  • Infrared cameras can track fast animals even during night-time

  • Most suitable infrared lenses focus high geometric resolution on animals, plants and landscapes

Thermal image of a vulcano

Ther­mo­graphy – Meas­ure­ment of Smal­lest Temper­ature Details

The vast majority of biologic processes only result in small temperature difference as they are always connected to a rather high energy consumption organisms try to avoid. Likewise, hydrological and geophysical anomalies within the thermal spectrum come with only lower thermal signatures.

InfraTec offers infrared camera models which suit the resulting demands in thermal resolution and thereby, guarantee for usable results of your studies. For instance, you can most precisely follow the thermal day cycles of plants which can lead to new results when monitoring the reaction of biotopes to external stress.

Event On Demand

High-Resol­u­tion Aerial Ther­mo­graphy

  • Aerial thermography: Definition, benefits, types, presence and future

  • Applications for thermography in airborne remote sensing and

  • Challenges of aerial thermography and technical requirements for an IR camera system

  • Important and relevant selection criteria

  • Accessories (hardware and software) needed to solve the measurement task

Request Recording

Case Studies about Ther­mo­graphy in Envir­on­mental Studies

InfraTec & KWS Saat - Thermography in Plant Research ©KWS SAAT SE & Co. KGaA

The Seeds of the Future

Environmental conditions today often tend towards extremes. Many areas are very humid and wet, while others are predominantly dry. Particularly in the second case, cultivating raw materials such as grain, beet or maize is a challenge. A challenge that KWS SAAT SE & Co. KGaA is facing. As part of its plant research, the company uses the VarioCAM® HD head 900 infrared camera from InfraTec to analyse the behaviour of plants during drought stress and pest infestation.

InfraTec & Highland Helicopters - Aerial Fire Mapping ©Highland Helicopters Dunedin, New Zealand

Catching Fire – Aerial Fire Mapping

Wildfires are a permanent threat for several regions around the world – and the global climate change is adding to the number and severity of these events. Fighting them is a huge challenge, strong winds, heat and inaccessibility make it even more difficult and dangerous for those who risk their life to protect others. One approach to tackle wildfires is the usage of airborne fire mapping.

thermal imaging for climate research

Ther­mo­graphy for Climate Research

Climate research is one of the most exposed types of academic research these days. With the continuous discussion about extreme weather events and long‐term implications of human‐made climate factors the related science has become a part of everyone´s daily life.

Study of bats - Picture credits: © iStock.com / fermate

Ther­mo­graphy for Envir­on­mental Studies

In order to protect bat populations firstly their ecology has to be understood but it can be very difficult to study the small, nocturnal mammals in the wild. Infrared thermography offers solutions to many of the problems faced by bat ecologists.

VarioCAM® High Definition: Klimaanlage nach Bienenart

Unin­ter­rupted Surveil­lance of Animal Beha­viour

Study of bats; nesting

The behaviour of animals can easily be tracked by visual cameras. But those cameras also just easily come to their limits. Additional light or activation sources for using visual surveillance technologies would be needed. But those will also interfere with the biological behaviour of animals. An infrared camera helps here as it allows to monitor even during absolute darkness. Beside of this you will also be able to detect perfectly camouflaged animals as their camouflage normally works in the visible spectrum only. Thereby for instance airborne countings of populations will become feasible using an infrared camera.
