Ther­mo­graphy for Material Testing

Efficient non-destructive testing of a wide variety of materials and defect types

  • Non-destructive testing saves time and costs

  • Analysis of process immanent temperature differences or externally induced heat streams

  • Pulsed activation allows the detection of below-surface errors

  • In-line applications for permanent quality control possible

  • Sensitive heat measurements to indicate areas of different mechanical stress

Material testing, stress test with thermal cameras from InfraTec - Picture credits: © iStock / kimtaro
Heating of synthetic substance under vibration
Detection of hidden damage liability
Test of a synthetic roller
Infrared thermal imaging to monitor the film production
0 | 6

Infrared Camera Systems Minimise Product Waste from Testing Proced­ures

Active thermography in the production of CFC plates

Material tests using thermal imaging save time and costs as test objects will not be destroyed during process. They can be used for further testing or locating quality problems that could be corrected. NDT tests with infrared camera systems provide good solutions with greater applications as they can be used for a wide range of different materials and types of defects. A huge advantage is that thermographic testing procedures can be applied to larger areas at once in comparison to ultrasonic or other methods that focus on smaller zones.

Passive Ther­mo­graphy as well as Active Heat Flow Ther­mo­graphy Locates Defects

Which method of thermography is used for material testing depends decisively on the question of the origin of the heating of the test object. In one test mode, it could stem directly from heating the test object gains during its production process. This case is referred to as passive thermography. The other possibility is called active heat flow thermography or just active thermography. This is when the test object will be thermally activated by an external energy input for instance by a halogen radiator or a flash lamp.
