The Right Choice for Challenging Test and Measurement Tasks

High-end Camera Series ImageIR®

The high-end thermographic cameras of the product series ImageIR® from InfraTec meet the highest demands in research and science, for non-destructive inspection as well as for process control. The modular concept enables excellent adaption to your specific measurement and inspection tasks. Cooled photon detectors of different types (InSb, MCT), spectral sensitivity ranges and formats are used. The numerous equipment options include powerful infrared full optics, filters and rotating aperture wheels, trigger and data transfer interfaces as well as motor focus units suitable for continuous operation.

infratec-thermography-imageir
InfraTec infrared camera tripod
0 | 2
InfraTec-icon-detector-1920x1536
Detector Format

Spatial resolution with detector formats with up to (1,920 × 1,536) infrared pixels

InfraTec Icon 5.2MP MicroScan
MicroScan

Integrated into camera, genuine temperature measured values

InfraTec Icon 15 mK
Thermal Resolution

Precise detection of smallest temperature differences

InfraTec Icon high speed mode
High-speed Mode

Due to Binning technology increase frame rates and thermal resolution at the same time

InfraTec Icon 105.000 Hz
Frame Rate

Analysis of high-speed dynamic temperature changes and processes

InfraTec icon modular design
Modular Design Concept

More flexibility for upgrades and changes of components

filter and aparture wheel
Rotating Filter/Aperture Wheel

Flexible filtering by inbuilt two filter- / aperture wheels with up to 25 combinations

InfraTec Icon Trigger
Process and Trigger Interface

Precise triggering with only 10 ns jitter

High end camera series ImageIR
Infrared camera ImageIR® 6300 Z Series from InfraTec

Infrared Zoom Camera Series – High-end Cameras with a Long Range

The radiometric infrared zoom cameras from InfraTec enable the detection of smallest objects and measurement of their temperatures even over long distances. With their various technical features, they are suitable for measurement tasks in research & development or quality assurance as well as in the field of security applications, e.g. for surveillance tasks.

ImageIR® 6300 Z
Small, light­weight, radiomet­ric­ally calib­rated and versatile in use

ImageIR® 8300 Z
Super-zoom infrared camera series with (640 × 512) IR pixels

ImageIR® 9300 Z
Super-zoom infrared camera series with (1,280 × 1,024) IR pixels

SWIR infrared camera ImageIR 8100/9100

SWIR Infrared Cameras – High-resol­u­tion and Radiomet­ric­ally Calib­rated

The SWIR infrared cameras from the ImageIR® series are high-resolution, radiometrically calibrated infrared cameras that operate in the short-wave infrared (SWIR) range. They have been specially developed for thermographic measurement tasks characterized by very high temperatures and challenging materials. For example, they allow emissivity-optimized measurements of temperatures on metallic surfaces – in high-temperature ranges between 300 °C and 1,700 °C. Further areas of application can be found, for example, in additive manufacturing and laser applications or in the metal industry in the field of welding processes or press hardening.

ImageIR® 8100
Radiomet­ric­ally calib­rated with (640 × 512) IR pixels

ImageIR® 9100
Radiomet­ric­ally calib­rated with (1,280 × 1,024) IR pixels

InfraTec ImageIR® High-End Infrared Camera Series

Models of the infrared camera series ImageIR® from InfraTec
Thermographic recording of a circuit board
Infrared camera ImageIR® 8800 Series from InfraTec
Thermal image of a soldering iron when a drop of water strikes
Contact to thermography division of InfraTec

You Need More Inform­a­tion about the ImageIR® Camera Series?

There is a ImageIR® matching perfectly your specific requirements. To find out which one it is, just check out all the models in detail.

United Kingdom & Irland
InfraTec GmbH Infrarotsensorik und MesstechnikGostritzer Straße 61 - 6301217 DresdenGERMANY

Innov­a­tions for Precise Perform­ance

Micro­Scan – Quad­ruple the Image Format

Behind the function is a fast-rotating MicroScan wheel, which is integrated into the camera. It ensures that four different individual exposures are taken per wheel revolution, which are offset laterally by half a pixel each. These individual exposures are brought together in real time into a thermogram with quadruple image format. Each pixel in the image represents a genuine temperature measured value and not an interpolated image point. In this way, thermography achieves a new quality due to thermal images providing a spatial resolution up to 3.7 Megapixels.

Further inform­a­tion about Micro­Scan

High-speed Mode – Increase Frame Rates and Thermal Resol­u­tion

If you want to analyze the thermal behavior of objects and processes from a wide variety of perspectives, you can use the high-speed mode for maximum flexibility. This function allows the camera to be used in two different operating modes. The standard mode suits best for depicting the smallest geometrical details. This allows users to record images with the native number of pixel of the camera detector. Switching to high-speed mode opens up the option of more than triple the frame rate, while the field of view (FOV) remains identical. This enables for most accurate time monitoring of fast processes. At the same time, the thermal resolution increases by a factor of 2 in high-speed mode, which additionally improves the analysis of temperature differences.

Further inform­a­tion about high-speed mode

Further Glossary Items relating to High-end Camera Series ImageIR®

Significantly extended temperature range using the MIT function

Multi Integration Time (MIT)

To measure temperatures spanning more than one calibration range requires the acquisition of multiple thermograms with different calibrations. This can be achieved by using our Multi Integration Time feature (MIT). This function increases the dynamic range up to 16 bit and significantly extends the temperature measurement ranges.

Thermal image during ignition of an airbag  Image Small

Window Mode (Subwin­dowing) – Capture of Rapid Sequences

The thermal imaging camera can be operated in full, half, quarter and sub mode. With the camera control software, it is possible to use the extended subwindowing function. Using click-and-drag, freely definable sections can be set up quickly and conveniently. A defined sub-frame of the detector is picked out to achieve these extremely high refresh rates.

Thermografie-Kameraserie ImageIR® mit neuer 10 GigE-Schnittstelle

10 GigE Inter­face for a Strong Increase in Output

The 10 Gigabit Ethernet interface of the high-end camera series ImageIR® opens this extremely fast transmission standard with a NIC specially developed by InfraTec. This works with optical or electrical transceiver modules that are easy to change and are called SFP+.

infrared cameras

Thermal Camera, Infrared Camera | Thermography Knowledge

A thermal camera – also called IR camera, thermal imaging camera or infrared camera – is a measuring instrument used for non-contact measurements of the surface temperature of objects.

Down­load HDR White­paper

Download the HDR white paper to get further information how it works and what the benefits are.

InfraTec ImageIR HDR Flyer

Indus­tries & Applic­a­tions for Camera Series ImageIR®

Active Thermography - Picture Credits: © Rainer / Fotolia.com

Active Ther­mo­graphy

Make use of active thermography for non-destructive and contact-free material testing, for both automated inline and offline solutions.

thermography for aerial photography

Aerial Ther­mo­graphy

Detect persons and objects in the field or monitor wide-area geologic properties or environmental damages.

thermal imaging for automotive applications

Auto­motive Industry

Infrared camera systems help you to secure a high product quality in production and at your suppliers.

thermal imaging in electronics

Elec­tronics & Elec­trical Engin­eering

Measure temperature distributions of smallest electronic components with infrared cameras.

thermal imaging in glass industry

Glass Industry

Measure correctly temperature distributions behind and on glass by using selected spectral filters.

microthermography

Micro-Ther­mo­graphy

Micro-thermography allows for the thermal analysis of smallest structures in the micrometer range, providing a detailed representation of the temperature distribution on complex electronic assemblies.

thermal imaging in chemical industry

Chem­ical Industry

Systematically control reactive process heat and display with infrared camera systems of InfraTec.

spectral ir thermography

Spec­tral Ther­mo­graphy

Using precision filters for specific applications you will measure exactly those spectral ranges being of interest to you.

WELD-CHECK by InfraTec
Non-destructive Testing

Welding Inspec­tion – WELD-CHECK

Using pulse thermography, WELD-CHECK enables you a quantitative assessment of the inspected welds.

Early fire detection WASTE-SCAN with thermal imaging
Obser­va­tion & Invest­ig­a­tion

Waste Bunker Fire Monitoring – WASTE-SCAN

Effectively secure your goods and appliances by integrating thermography into an automated early fire detection solution.

thermal imaging for thermal optimisation

Thermal Optim­isa­tion

Identify possible problems already in the development phase well before serial production.

thermal imaging in aviation

Aerospace Industry

Comply with highest security demands by applying state-of-the-art infrared camera systems.

additive manufacturing

Additive Manu­fac­turing

By in-line monitoring of thermal process parameters, infrared cameras from InfraTec support the optimisation of additive manufacturing processes.
